Description
Two manual pumps attached to the rear handle–that’s the distinguishing feature of the Manual Drum Rotator. You pump the handle back and forth, enabling the carriage to rise. The design is simple, yet effective:minimal force and letting the hydraulic power work the magic. However, when the number of drums gets between 5-10 drums a day, we highly recommend you explore our electric model or pneumatic model.
- Tilt-to-load design
Allows easy and ergonomic drum loading at ground level - End-over-end tumbling action
Ensures thorough and uniform mixing - Closed-drum mixing capability
Mix contents without opening the drum - Secure drum holding system
Keeps the drum stable during operation - Heavy-duty industrial construction
Built for reliable and continuous use
- Chemical and process industries
Mixing liquids, powders, and compounds - Paint, coatings, and adhesives
Re-blending settled materials - Food and ingredient processing
Homogenizing contents in sealed drums - Oil and lubricant handling
Restoring consistency before use - General industrial mixing operations
Efficient and ergonomic drum mixing
Specifications
STM01-DRU01
STM01-DRU01
Universal Drum Rotator (Manual)
Safe working load (SWL)
350kg
Universal band
Adjustable for drums from 350-600mm in diameter
Tipping clearances
1500mm at 15° downward tip angle
1400mm at 30° downward tip angle
Number of pumps
80 pumps to maximum height
Straddle leg width
Inside width 850mm
Outside width 1080mm
